Fiberglass Fabricated Sectional Water Tank

Water tank plate size: 1000*1000mm; 1000*500mm; 500*500mm

The fiberglass water tank is assembled entirely from high-quality SMC water tank plates. Its characteristic is that it uses food-grade resin, so the water quality is good, clean, and pollution-free. The product has the characteristics of high strength, corrosion resistance, beautiful appearance, long service life, and easy maintenance and management.

Inquiry

Fiberglass Fabricated Sectional Water Tank Installation Video

Product Description

FRP water tanks are divided into two types: FRP-assembled FRP water tanks and SMC water tanks. SMC water tanks are characterized by their lightweight, no rust, no leakage, good water quality, wide range of use, long service life, good insulation performance, beautiful appearance, easy installation, and cleaning It has the characteristics of easy maintenance and strong adaptability. It is an ideal product as a water storage facility for public living, firefighting, and industrial water.

The structural design of the combined water tank mainly determines the structural size through the calculation of structural strength and stiffness. The design requirements are a beautiful appearance, convenient construction, and easy overall assembly and disassembly. The plate structure is reinforced with a spherical surface. Compared with steel plate water tanks and concrete water tanks, it has its own characteristics. Although the initial investment of the combined water tank is larger than that of the traditional water tank, it has the advantages of small weight, easy installation, easy maintenance, and cleaning, etc., so it will be welcomed by the majority of users.



Installation method

1. During installation, leave an access channel of not less than 800mm between the box and the wall, and the top and bottom of the box should not be less than 500mm;

2. During civil construction, the concrete strip foundation must be prepared first;

3. After assembly, the water outlet pipe and drain pipe should be closed, and the water inlet pipe should be opened. If there is no leakage for 24 hours after filling with water, it is considered qualified;

4. Provide construction power supply and inspection sealing water at the construction site.

Notes on installation and debugging:

The foundation of the water tank can be made of concrete strip beams or I-beams. There is a breathable air filter device on the top corner of the water tank. Latent are used inside the water tank. Each nozzle flange is a 1.0MPa standard flange.

Application scope

1. FRP water tanks are used for domestic and fire-fighting water in ordinary residences, commercial and residential buildings, office buildings, residential areas, government agencies, schools, hotels, etc.;

2. Water for production and domestic use in industrial and mining enterprises;

3. Water for various types of circulating water, cooling water, and hot water supply systems;

4. Acid-base reserve.
